Weight
3.3 kg excluding battery.
Electric Thrusters
H01 Electric Thruster
A 2000W higher-output electric thruster documented at 35 kgf maximum thrust.
PRODUCT DATA
Specifications for H01
Product-manual parameters relevant to this product category.
- Rated power
- 2000 W
- Maximum thrust
- 35 kgf
- Maximum thrust
- 77.1 lbf
- Weight
- 3.3 kg
- Rated rotational speed
- 2500 r/min
- Drive settings
- 6 forward, 2 reverse
- Compatible batteries
- B30H, B50H
- Recommended capacity
- Professional heavy-duty / commercial
- Operating temperature
- 0–40°C
- Waterproof rating
- IP68
PRODUCT MEDIA
See the product clearly.
TECHNICAL FEATURES
What this product is built to do.
Drive settings
Six forward settings and two reverse settings.
Manual compatibility
The manual lists B30H and B50H batteries.
Temperature reference
The current manual states 0-40°C for operating and storage. Confirm product version and conditions before contractual use.
APPLICATION
Plan the right configuration.
Recommended use
Higher-load and commercial project evaluation requiring engineering review of boat, battery, mounting, load, and operating conditions.
Performance context
Manual reference at a 100 kg load: 5, 7, 8-9, 9-10, 10-12, and 12-15 km/h across six forward settings.
COMPATIBILITY
Build the complete system.
DOCUMENTS
Review model-specific information.
Find available manuals, product files and supporting documents in the IFUNGOO download center.
SAMPLE TO SCALE
Evaluate this product for your market.
Share the vessel, application, quantity and target market. IFUNGOO will review the appropriate product or system configuration.
