Weight
5.5 kg.
Marine Batteries
B3 Marine Battery
A 22.4V, 30Ah, 672Wh LiFePO4 battery listed for selected Y Series systems.
PRODUCT DATA
Specifications for B3
Product-manual parameters relevant to this product category.
- Battery type
- Lithium iron phosphate (LiFePO4)
- Capacity
- 30 Ah
- Energy
- 672 Wh
- Nominal voltage
- 22.4 V
- Weight
- 5.5 kg
- Standard charging time
- 7 h
- Floatable
- No
- Dimensions
- 269.9 × 220.94 × 125.8 mm
- Charging temperature
- 5–35°C
- Waterproof rating
- IP68
PRODUCT MEDIA
See the product clearly.
TECHNICAL FEATURES
What this product is built to do.
Battery type
LiFePO4 in the current manual.
Charging reference
5-35°C ambient and 7 hours standard slow charge.
APPLICATION
Plan the right configuration.
Recommended use
Compatible Y Series systems and Y03 dual-drive evaluation where B3 is explicitly listed.
Performance context
Runtime depends on the complete system and operating conditions.
COMPATIBILITY
Build the complete system.
DOCUMENTS
Review model-specific information.
Find available manuals, product files and supporting documents in the IFUNGOO download center.
SAMPLE TO SCALE
Evaluate this product for your market.
Share the vessel, application, quantity and target market. IFUNGOO will review the appropriate product or system configuration.
