Weight
4.95 kg.
Marine Batteries
B1 Marine Battery
A 22.2V, 36Ah, 799.2Wh lithium-polymer battery listed for selected Y Series systems.
PRODUCT DATA
Specifications for B1
Product-manual parameters relevant to this product category.
- Battery type
- Ternary lithium battery
- Capacity
- 36 Ah
- Energy
- 799.2 Wh
- Nominal voltage
- 22.2 V
- Weight
- 4.95 kg
- Standard charging time
- 8 h
- Floatable
- Yes
- Dimensions
- 269.9 × 220.94 × 125.8 mm
- Charging temperature
- 5–35°C
- Waterproof rating
- IP68
PRODUCT MEDIA
See the product clearly.
TECHNICAL FEATURES
What this product is built to do.
Battery type
Li Polymer in the current manual.
Charging reference
5-35°C ambient and 8 hours standard slow charge.
APPLICATION
Plan the right configuration.
Recommended use
Compatible Y Series product evaluation where the specific product record lists B1.
Performance context
Runtime depends on thruster, load, hull, installation, water, mode, temperature, and battery condition.
COMPATIBILITY
Build the complete system.
DOCUMENTS
Review model-specific information.
Find available manuals, product files and supporting documents in the IFUNGOO download center.
SAMPLE TO SCALE
Evaluate this product for your market.
Share the vessel, application, quantity and target market. IFUNGOO will review the appropriate product or system configuration.
